Overview
The unique mixing blades are fully welded to the rotating drum, allowing the mixture to be completely fluidized with each rotation. The drum mixer operates at a low speed inside without any moving parts, resulting in a shear-free, gentle mixing action. In the fluidized mixture, powders and particles of different bulk densities and sizes can move freely, ensuring fast and efficient mixing.
Device Features
Low power consumption
zero residue rate
sanitary design
gentle stirring
| 型号 Model |
允许工作容积 Allowable working volume |
滚筒直径 Drum diameter |
电机功率 Motor power(KW) |
设备重量 Equipment weight(KG) |
外形尺寸 L Overall dimension(mm) |
W | H |
| PPT-GT-0.5 | 200-300L | φ900 | 0.75 | 1000 | 1800 | 1000 | 1600 |
| PPT-GT-1 | 300-500L | φ1060 | 3.7-5.5 | 1500 | 2290 | 1400 | 2000 |
| PPT-GT-2 | 700-1000L | φ1400 | 5.5-11 | 2000 | 2950 | 1900 | 2300 |
| PPT-GT-5 | 1500-2500L | φ1800 | 11 | 5000 | 3400 | 2240 | 2700 |
| PPT-GT-10 | 3500-5000L | φ2200 | 37-45 | 7500 | 4400 | 3550 | 3100 |
| PPT-GT-20 | 7000-10000L | φ2600 | 45-55 | 10000 | 5100 | 4020 | 3560 |
| PPT-GT-30 | 12000-15000L | φ3000 | 75-90 | 15000 | 5600 | 4760 | 3550 |
| PPT-GT-40 | 15000-24000L | φ3300 | 90 | 21000 | 6800 | 4810 | 4390 |
